IP66 LED Module Waterproof Luminaire
-
Driver:Meanwell driver or other options
-
Reflector:MCPCB or PCB for your option
-
Body and diffuser could meet the IK08,and 850 degree glow wire test requirment
-
Perfect replacement for the whole set of T8 fluorescent lighting fixture
-
Save up to 60% in electricity consumption compared to fluorescent lighting fixture
-
Lightweight body material .corrosion resistant,waterproof and dustproof
-
Easy Installation with fast connection design,shorten the installation process and save labor cost
-
It could be fitted with the Microwave sensor,fitted with the Emergency battery to meet the requirment
-
Suitable for supermarket,underground parking,warehouse,etc.
|
Model No. |
PS08-20W-650 |
PS08-20W-1220 |
PS08-30W-1220 |
PS08-36W-1220 |
PS08-45W-1220 |
PS08-36W-1560 |
PS08-54W-1560 |
PS08-65W-1560 |
|||||||||
|
Lens |
OPAL |
CLEAR |
OPAL |
CLEAR |
OPAL |
CLEAR |
OPAL |
CLEAR |
OPAL |
CLEAR |
OPAL |
CLEAR |
OPAL |
CLEAR |
OPAL |
CLEAR |
|
|
CCT@ Lumen Output(lm) |
2700K – 6500K |
||||||||||||||||
|
2500 |
2600 |
2500 |
2600 |
3750 |
3900 |
4500 |
4680 |
5600 |
5850 |
4500 |
4680 |
6750 |
7020 |
8100 |
8450 |
||
|
Certificate |
CE-LVD EMC ROHS GS CB ENEC SAA C-TICK |
||||||||||||||||
|
Power(W±10%) |
20W |
20W |
30W |
36W |
45W |
36W |
54W |
65W |
|||||||||
|
LED type |
SMD 2835,0.5W |
||||||||||||||||
|
Input Voltage(V) |
AC220-240V,50/60HZ |
||||||||||||||||
|
Efficiency |
OPAL LENS 125lm/w |
||||||||||||||||
|
CLEAR LENS 130lm/w |
|||||||||||||||||
|
CRI |
80 |
||||||||||||||||
|
Beam Angle( °) |
120 |
||||||||||||||||
|
Driver Type |
OSRAM/TRIDONIC/PHIUPS or Chinese driver for option |
||||||||||||||||
|
LED Chips |
EVERLIGHT/LG/SAMSUNG |
||||||||||||||||
|
Temperature |
-20 ℃-35 ℃ |
||||||||||||||||
|
Humidity |
10%-90% |
||||||||||||||||
|
Warranty |
Up to 3 Year |
||||||||||||||||
|
IP |
IP66 |
||||||||||||||||
|
IK |
08 |
||||||||||||||||
|
GLOW WIRE TEST |
Pass 850 ℃ |
||||||||||||||||
|
Material |
Polycarbonate material |
||||||||||||||||
|
Net Weight(kg) |
1.00 |
1.70 |
2.10 |
||||||||||||||
|
Product Size(mm) |
670×97×82 |
1240×97×82 |
1580×97×82 |
||||||||||||||
